Bison-Toolmex, GS Tooling & Techniks CAT 40 End Mill Holders

Projection
L Bison-Toolmex GS Tooling Techniks

Standard
Part No. Price Balanced 15K @ G6.3
Part No. Price Balanced 20K @ G2.5
Part No. Price Balanced 20K @ G2.5
Part No. Price Balanced 10K SIMIS
Part No. Price Balanced 10K @ G6.3
Part No. Price

Size: 1/8" CAT 40 End Mill Holder

1.375" - - 7-188-002 $88.75 - - - - - - - -

1.75" - - - - - - $90.50 - - 22907-1.75 $79.95

2.375" - - - - - - - - CAT40SLN1/8 $60.50 22907 $71.50

2.50" 7-185-405 $81.50 7-185-004 $100.95 - - $67.75 - - - -

4.00" - - - - - - $91.95 - - - -

5.00" - - - - - - $91.95 - - 22907-5.00-RR $117.75

6.00" - - - - - - - - - - 22907-6 $96.75

Size: 3/16" CAT 40 End Mill Holder

1.375" - - 7-188-006 $97.25 - - - - - - - -

1.75" - - - - - - $90.50 - - 22909-1.75 $79.95

2.50" 7-185-407 $82.50 7-185-008 $96.95 7-185-208 $66.75 $67.75 CAT40SLN3/16 $60.50 22909 $71.50

4.00" 7-185-4074 $88.00 - - - - $84.75 - - - -

4.72" - - - - - - - - - - 22909-4.72-RR $117.75

6.00" - - - - - - $91.95 - - 22909-6 $96.95

Size: 1/4" CAT 40 End Mill Holder

1.375" - - 7-188-012 $94.50 - - - - - - - -

1.75" - - - - - - $67.75 CAT40SLN1/4-1.75 $60.50 22911-1.75 $71.50

2.50" 7-185-409 $80.25 7-185-014 $82.50 - - $67.75 - - 22911-2.5 $71.50

3.00" - - - - - - - - CAT40SLN1/4 $60.50 22911 $71.50

4.00" 7-185-4094 $90.25 - - - - $72.75 - - - -

4.72" - - - - - - - - - - 22911-4.72-RR $117.75

5.00" - - - - - - $79.00 - - - -

6.00" - - - - - - $107.25 - - 22911-6 $82.25

Size: 5/16" CAT 40 End Mill Holder

1.375" - - 7-185-018 $86.25 - - - - - - - -

1.75" - - - - - - $79.95 - - 22913-1.75 $79.95

2.50" 7-185-4115 $73.25 7-185-020 $82.95 - - $67.75 - - 22913-2.5 $79.95

3.00" - - - - - - - - - - 22913 $71.50

4.00" 7-185-4117 $90.25 - - - - $72.75 - - - -

4.72" - - - - - - - - - - 22913-4.72-RR $117.75

6.00" - - - - - - $107.25 - - - -

Size: 3/8" CAT 40 End Mill Holder

1.375" 7-185-024 $88.75 - - - - - - - -

1.75" - - - - - - $67.75 CAT40SLN3/8-1.75 $60.50 22915-1.75 $71.50

2.50" 7-185-412 $75.50 7-185-026 $89.50 - - $67.75 - - 22915-2.5 $79.95

3.00" - - - - - - - CAT40SLN3/8 $60.50 22915 $71.50

4.00" - - - - - - $72.75 - - - -

4.50" - - - - - - $83.95 - - - -

4.72" - - - - - - - - - - 22915-4.72-RR $117.75

5.00" 7-185-4122 $83.50 - - - - $83.95 - - 22915-5 $130.25

6.00" - - - - - - $107.25 - - - -

Size: 7/16" CAT 40 End Mill Holder

1.75" - - - - - - - - - - 22916-1.75 $79.95

2.50" 7-185-4123 $73.25 7-185-030 $82.95 - - $78.25 - - 22916 $71.50

4.00" 7-185-4127 $80.25 - - - - - - - - - -

Size: 1/2" CAT 40 End Mill Holder

1.75" - - 7-185-034 $87.00 - - $67.75 CAT40SLN1/2-1.75 $60.50 22917-1.75 $71.50

2.50" - - - - - - $67.75 - - 22917-2.5 $71.50

2.62" 7-185-413 $75.50 7-185-036 $80.75 7-185-236 $67.95 $67.75 - - 22971-2.63 $71.50

3.00" - - - - - - - - CAT40SLN1/2 60.50 22917 $71.50

4.00" - - - - - - $75.95 - - - -

4.62" - - - - - - $83.95 - - 22917-4.63 $92.50

4.72" - - - - - - - - - - 22917-4.72-RR $117.75

5.00" 7-185-417 $83.50 - - - - $83.95 - - - -

6.00" - - - - - - $107.25 - - - -

Size: 5/8" CAT 40 End Mill Holder

1.75" - - 7-185-040 $85.95 - - $67.75 - - 22919-1.75 $71.50

2.50" - - - - - - $67.75 - - - -

3.00" - - - - - - $67.75 CAT40SLN5/8 $60.50 22919 $71.50

3.75" 7-185-431 $79.50 7-185-042 $94.00 - - - - - - 22920 $79.95

4.00" - - - - - - $72.75 - - - -

5.00" - - - - - - $87.95 - - - -

5.50" 7-185-437 $84.25 - - - - - - - - - -

5.75" - - - - - - - - - - 22920-5.75 $102.95

6.00" - - - - - - $98.50 - - - -

Size: 3/4" CAT 40 End Mill Holder

1.75" - - 7-185-048 $85.95 - - $73.50 CAT40SLN3/4-1.75 $67.25 22921-1.75 $79.95

2.50" - - - - - - $67.75 - - - -

3.00" - - - - - - $67.75 - - 22921-3 $71.50

3.50" - - - - - - $67.75 CAT40SLN3/4 $60.50 22921 $71.50

3.75" 7-185-441 $79.50 7-185-050 $85.95 7-185-250 $70.00 - - - - - -

4.00" - - - - - - $75.95 - - - -

5.00" - - - - - - $87.95 - - 22921-5 $96.75

5.50" 7-185-447 $84.25 - - - - - - - - - -

6.00" - - - - - - $101.75 - - - -

Size: 7/8" CAT 40 End Mill Holder

1.75" - - 7-185-054 $89.95 - - $68.75 - - - -

3.50" 7-185-450 $82.95 7-185-056 $111.75 - - $71.75 - - 22923 $79.95

4.00" 7-185-451 $84.95 - - - - - - - - - -

6.00" - - - - - - $108.95 - - - -

Size: 1" CAT 40 End Mill Holder

1.75" - - - - - - $75.00 CAT40SLN1-1.75 $67.25 22925-1.75 $79.95

2.00" - - 7-185-060 $92.75 - - - - - - - -

3.00" - - - - - - $72.75 - - 22925-3 $95.75

4.00" 7-185-461 $88.25 7-185-062 $116.50 7-185-262 $71.75 $75.95 CAT40SLN1 $67.50 22925 $79.95

5.00" - - - - - - $83.95 - - - -

6.00" 7-185-465 $95.95 - - - - $101.75 - - 22925-6 $113.50

Size: 1-1/4" CAT 40 End Mill Holder

2.00" - - - - - - $77.50 CAT40SLN1-1/4-2 $74.75 22927-2 $88.25

4.00" - - - - - - $79.00 - - 22927-4 $88.25

4.25" 7-185-471 $89.25 7-185-068 $95.75 - - $88.75 - - - -

4.375" 7-185-472 $93.50 - - - - - - - - - -

4.60" - - - - - - - - - - 22927 $88.25

6.00" 7-185-475 $101.95 - - - - $104.00 - - 22927-6 $126.00

Size: 1-1/2" CAT 40 End Mill Holder

4.00" - - - - - - $90.50 - - - -

4.50" - - - - - - - - - - 22929 $100.95

4.62" 7-185-481 $115.75 - - - - $106.50 - - - -

6.00" 7-185-485 $132.00 - - - - $120.25 - - - -

Projection L	Bison-Toolmex	GS Tooling	Techniks
Standard Part No.	Price	Balanced 15K @ G6.3 Part No.	Price	Balanced 20K @ G2.5 Part No.	Price	Balanced 20K @ G2.5 Part No.	Price	Balanced 10K SIMIS Part No.	Price	Balanced 10K @ G6.3 Part No.	Price
Size: 1/8" CAT 40 End Mill Holder
1.375"	-	-	7-188-002	$88.75	-	-	-	-	-	-	-	-
1.75"	-	-	-	-	-	-		$90.50	-	-	22907-1.75	$79.95
2.375"	-	-	-	-	-	-	-	-	CAT40SLN1/8	$60.50	22907	$71.50
2.50"	7-185-405	$81.50	7-185-004	$100.95	-	-		$67.75	-	-	-	-
4.00"	-	-	-	-	-	-		$91.95	-	-	-	-
5.00"	-	-	-	-	-	-		$91.95	-	-	22907-5.00-RR	$117.75
6.00"	-	-	-	-	-	-	-	-	-	-	22907-6	$96.75
Size: 3/16" CAT 40 End Mill Holder
1.375"	-	-	7-188-006	$97.25	-	-	-	-	-	-	-	-
1.75"	-	-	-	-	-	-		$90.50	-	-	22909-1.75	$79.95
2.50"	7-185-407	$82.50	7-185-008	$96.95	7-185-208	$66.75		$67.75	CAT40SLN3/16	$60.50	22909	$71.50
4.00"	7-185-4074	$88.00	-	-	-	-		$84.75	-	-	-	-
4.72"	-	-	-	-	-	-	-	-	-	-	22909-4.72-RR	$117.75
6.00"	-	-	-	-	-	-		$91.95	-	-	22909-6	$96.95
Size: 1/4" CAT 40 End Mill Holder
1.375"	-	-	7-188-012	$94.50	-	-	-	-	-	-	-	-
1.75"	-	-	-	-	-	-		$67.75	CAT40SLN1/4-1.75	$60.50	22911-1.75	$71.50
2.50"	7-185-409	$80.25	7-185-014	$82.50	-	-		$67.75	-	-	22911-2.5	$71.50
3.00"	-	-	-	-	-	-	-	-	CAT40SLN1/4	$60.50	22911	$71.50
4.00"	7-185-4094	$90.25	-	-	-	-		$72.75	-	-	-	-
4.72"	-	-	-	-	-	-	-	-	-	-	22911-4.72-RR	$117.75
5.00"	-	-	-	-	-	-		$79.00	-	-	-	-
6.00"	-	-	-	-	-	-		$107.25	-	-	22911-6	$82.25
Size: 5/16" CAT 40 End Mill Holder
1.375"	-	-	7-185-018	$86.25	-	-	-	-	-	-	-	-
1.75"	-	-	-	-	-	-		$79.95	-	-	22913-1.75	$79.95
2.50"	7-185-4115	$73.25	7-185-020	$82.95	-	-		$67.75	-	-	22913-2.5	$79.95
3.00"	-	-	-	-	-	-	-	-	-	-	22913	$71.50
4.00"	7-185-4117	$90.25	-	-	-	-		$72.75	-	-	-	-
4.72"	-	-	-	-	-	-	-	-	-	-	22913-4.72-RR	$117.75
6.00"	-	-	-	-	-	-		$107.25	-	-	-	-
Size: 3/8" CAT 40 End Mill Holder
1.375"	7-185-024	$88.75			-	-	-	-	-	-	-	-
1.75"	-	-	-	-	-	-		$67.75	CAT40SLN3/8-1.75	$60.50	22915-1.75	$71.50
2.50"	7-185-412	$75.50	7-185-026	$89.50	-	-		$67.75	-	-	22915-2.5	$79.95
3.00"	-	-	-	-	-	-	-		CAT40SLN3/8	$60.50	22915	$71.50
4.00"	-	-	-	-	-	-		$72.75	-	-	-	-
4.50"	-	-	-	-	-	-		$83.95	-	-	-	-
4.72"	-	-	-	-	-	-	-	-	-	-	22915-4.72-RR	$117.75
5.00"	7-185-4122	$83.50	-	-	-	-		$83.95	-	-	22915-5	$130.25
6.00"	-	-	-	-	-	-		$107.25	-	-	-	-
Size: 7/16" CAT 40 End Mill Holder
1.75"	-	-	-	-	-	-	-	-	-	-	22916-1.75	$79.95
2.50"	7-185-4123	$73.25	7-185-030	$82.95	-	-		$78.25	-	-	22916	$71.50
4.00"	7-185-4127	$80.25	-	-	-	-	-	-	-	-	-	-
Size: 1/2" CAT 40 End Mill Holder
1.75"	-	-	7-185-034	$87.00	-	-		$67.75	CAT40SLN1/2-1.75	$60.50	22917-1.75	$71.50
2.50"	-	-	-	-	-	-		$67.75	-	-	22917-2.5	$71.50
2.62"	7-185-413	$75.50	7-185-036	$80.75	7-185-236	$67.95		$67.75	-	-	22971-2.63	$71.50
3.00"	-	-	-	-	-	-	-	-	CAT40SLN1/2	60.50	22917	$71.50
4.00"	-	-	-	-	-	-		$75.95	-	-	-	-
4.62"	-	-	-	-	-	-		$83.95	-	-	22917-4.63	$92.50
4.72"	-	-	-	-	-	-	-	-	-	-	22917-4.72-RR	$117.75
5.00"	7-185-417	$83.50	-	-	-	-		$83.95	-	-	-	-
6.00"	-	-	-	-	-	-		$107.25	-	-	-	-
Size: 5/8" CAT 40 End Mill Holder
1.75"	-	-	7-185-040	$85.95	-	-		$67.75	-	-	22919-1.75	$71.50
2.50"	-	-	-	-	-	-		$67.75	-	-	-	-
3.00"	-	-	-	-	-	-		$67.75	CAT40SLN5/8	$60.50	22919	$71.50
3.75"	7-185-431	$79.50	7-185-042	$94.00	-	-	-	-	-	-	22920	$79.95
4.00"	-	-	-	-	-	-		$72.75	-	-	-	-
5.00"	-	-	-	-	-	-		$87.95	-	-	-	-
5.50"	7-185-437	$84.25	-	-	-	-	-	-	-	-	-	-
5.75"	-	-	-	-	-	-	-	-	-	-	22920-5.75	$102.95
6.00"	-	-	-	-	-	-		$98.50	-	-	-	-
Size: 3/4" CAT 40 End Mill Holder
1.75"	-	-	7-185-048	$85.95	-	-		$73.50	CAT40SLN3/4-1.75	$67.25	22921-1.75	$79.95
2.50"	-	-	-	-	-	-		$67.75	-	-	-	-
3.00"	-	-	-	-	-	-		$67.75	-	-	22921-3	$71.50
3.50"	-	-	-	-	-	-		$67.75	CAT40SLN3/4	$60.50	22921	$71.50
3.75"	7-185-441	$79.50	7-185-050	$85.95	7-185-250	$70.00	-	-	-	-	-	-
4.00"	-	-	-	-	-	-		$75.95	-	-	-	-
5.00"	-	-	-	-	-	-		$87.95	-	-	22921-5	$96.75
5.50"	7-185-447	$84.25	-	-	-	-	-	-	-	-	-	-
6.00"	-	-	-	-	-	-		$101.75	-	-	-	-
Size: 7/8" CAT 40 End Mill Holder
1.75"	-	-	7-185-054	$89.95	-	-		$68.75	-	-	-	-
3.50"	7-185-450	$82.95	7-185-056	$111.75	-	-		$71.75	-	-	22923	$79.95
4.00"	7-185-451	$84.95	-	-	-	-	-	-	-	-	-	-
6.00"	-	-	-	-	-	-		$108.95	-	-	-	-
Size: 1" CAT 40 End Mill Holder
1.75"	-	-	-	-	-	-		$75.00	CAT40SLN1-1.75	$67.25	22925-1.75	$79.95
2.00"	-	-	7-185-060	$92.75	-	-	-	-	-	-	-	-
3.00"	-	-	-	-	-	-		$72.75	-	-	22925-3	$95.75
4.00"	7-185-461	$88.25	7-185-062	$116.50	7-185-262	$71.75		$75.95	CAT40SLN1	$67.50	22925	$79.95
5.00"	-	-	-	-	-	-		$83.95	-	-	-	-
6.00"	7-185-465	$95.95	-	-	-	-		$101.75	-	-	22925-6	$113.50
Size: 1-1/4" CAT 40 End Mill Holder
2.00"	-	-	-	-	-	-		$77.50	CAT40SLN1-1/4-2	$74.75	22927-2	$88.25
4.00"	-	-	-	-	-	-		$79.00	-	-	22927-4	$88.25
4.25"	7-185-471	$89.25	7-185-068	$95.75	-	-		$88.75	-	-	-	-
4.375"	7-185-472	$93.50	-	-	-	-	-	-	-	-	-	-
4.60"	-	-	-	-	-	-	-	-	-	-	22927	$88.25
6.00"	7-185-475	$101.95	-	-	-	-		$104.00	-	-	22927-6	$126.00
Size: 1-1/2" CAT 40 End Mill Holder
4.00"	-	-	-	-	-	-		$90.50	-	-	-	-
4.50"	-	-	-	-	-	-	-	-	-	-	22929	$100.95
4.62"	7-185-481	$115.75	-	-	-	-		$106.50	-	-	-	-
6.00"	7-185-485	$132.00	-	-	-	-		$120.25	-	-	-	-

Bison-Toolmex

Features

Produced according to AT3 specifications
Made of alloy forged steel for a long, durable service life
Hardened to RC 56-60 and ground to ensure maximum accuracy
Draw Bar Threads: CAT 40 5/8"-11
Through the spindle coolant capability

GS Tooling

Features

DIN coolant thru the flange at no extra charge
Traverse ground shank to obtain optimum accuracy
Meets or exceeds ANSI specifications
.0002” TIR or better ensures the best possible cutting tool life

Techniks

Features

I.D. hole tolerance is H5 (Best in Industry)
T.I.R - 0.0002"
Balanced to 10,000 RPM to save spindle bearing life
Taper ground to AT3 for maximum spindle contact
Each holder lab certified for dimensional accuracy
